SPECIFICATIONS
MODEL
DRIVE X 纏繞機
PERFORMANCE
Maximum wrapping Speed 20-30 loads/Hour
Load Size Diagonal 1753mm(Recommended)
Maximum Wrapping Height 2200mm(2800mm Optional)
Maximum Load Weight 2000kg
TURNTABLE SYSTEM
Turntable Speed 12RPM
Turntable size 1650mm
Turntable Drive 1PH
PERFORMANCE FEATURES
Film Cut and Clamp Automatic
Pallet Grip Standard
Intelli-Sensor Standard
Standard Film Width 500mm
Constant Film Delivery Force Standard
Standard Pre-Stretch 300%
Wrap Force Variable(Electric)
Film Capacity 250mm Roll Diametery
Film Delivery System Power Roller-Stretch Plus
Remote Control system Standard
EIGHT AND SIZE纏繞機
Machine Weight 660kg
Machine Size L2700W 1650 H2475
SERVICE REQUIREMENTS
Cotrol System SIEMENS Control System
V0ltage 220V 16A
